Rembra RT
CT simulator
Rembra RT
CT simulator
When you can target tumors more accurately than before, that’s mastering the art of personalized CT simulation. Philips Rembra RT can help you to delineate tumors more precisely to spare healthy tissue. Your patients count on you to design a journey for the best possible outcome, and Rembra RT is designed to offer you accuracy and intuitive guidance at every step.
Highly accurate
Enhanced experience
Smart for life
Features
AI reconstruction elevates image clarity while keeping radiation dose low
Precise Image [1] AI reconstruction uses the power of a deep-learning neural network to support image interpretation in CT Sim. Precise Image [1] simultaneously delivers 60% improved low contrast detectability, 85% lower noise and 80% lower radiation dose. [2] All reference protocols are reconstructed in under a minute (excluding 4DCT).
Dedicated to your long-term success
Rembra RT is built to last up to 20 years with required maintenance and commercial upgrades. In addition, the industry-first Tube for Life guarantee ensures that, if necessary, any tube replacement within a 10-year period is covered by Philips [3]. The vMRC tube features the latest innovation of Philips smart card technology that allows us to monitor tube life and potential downtime. AI-enabled Remote Services increase uptime and reduce unplanned equipment downtime through proactive remote monitoring and serviceability. [4]
Reduce rescans and minimize motion artifacts with Reach 4D
Extends 4D scan coverage in both scan length and breath rate with enhanced tube time to scan lungs to liver - up to 500 scan seconds with improved breath rates from 4 to 40. Create intensity projections (MIPs/MinIPs/AIPs) on the console, with waveform visualization at the gantry touchscreen controls. Apply Metal Artifact Reduction for Orthopedic Implants (O-MAR) to 4D scans. Designed to work with motion management to reduce target volumes, artifacts and noise while sparing healthy tissue.
Specifications
- Specifications
- Generator power
- 80 kW (72 kW optional)
- Effective power with iDose4
- 105 kW
- Slices
- 128
- Coverage
- 40 mm
- Maximum scannable range (ax)
- Standard: 1,860 mm High Performance: 2,290 mm
- kVp stations
- 70 kV, 80 kV, 100 kV, 120 kV, 140 kV
Disclaimer
1. Feature availability subject to local regulatory clearance/approvals. Not available for sale in the USA.
2. In clinical practice, the use of Precise Image may reduce CT patient dose depending on the clinical task, patient size and anatomical location. A consultation with a radiologist and a physicist should be made to determine the appropriate dose to obtain diagnostic image quality for the particular clinical task. Dose reduction assessments were performed using reference body protocols with 1.0 mm slices at the “Smoother” setting, and tested on the MITA CT IQ Phantom (CCT189, The Phantom Laboratory) assessing the 10 mm pin and compared to filtered back projection. A range is seen across the 4 pins, using a channelized hoteling observer tool, that includes lower image noise by 85% and improved low-contrast detectability from 0% to 60% at 50% to 80% dose reduction. NPS curve shift is used to evaluate image appearance, as measured on a 20 cm water phantom in the center 50 mm x 50 mm region of interest, with an average shift of 6% or less. Data on file.
3. Life of the product is defined by Philips as 10 years. Tube for Life guarantee availability varies by country. Please contact your local Philips sales representative for details.
Actual service experience may vary depending on contract type, system configuration, geographical location and external factors such as parts availability. Performance guarantees, including uptime, are subject to the terms and conditions of individual service agreements.
5. The Extended Field of View (EFOV) of 85 cm is intended solely for use in treatment preparation and the planning/simulation of radiation therapy. It cannot be used for diagnostic purposes. The water equivalent material external contour deviation of body system phantom positioned (partially) outside scan FOV with phantom edge adjacent to bore cover shall be within 1mm in terms of mean Hausdorff distance compared to the true external contour.
6. As compared to Big Bore RT.
7. Optional.
